Electromagnet J12-27YC

Main technical data:

Rated Magnetic (N)	Rated Stroke (mm)	Full stroka (mm)	Power Consumption (W)	Oil Pressure Duration (Mpa)
27	2.8	≥6.5	≤30	16
Max Operation Frequency (t/h)	Duty Cycle (%)	Insulation Class	Supply Voltage Tolerance	Working Llfe
12000	100	H	+10～-15
