Main technical data:
Rated Magnetic (N) | Rated Stroke (mm) | Full stroka (mm) | Power Consumption (W) | Oil Pressure Duration (Mpa) |
20 | 3 | ≥6.5 | ≤30 | 21 |
Max Operation Frequency (t/h) | Duty Cycle (%) | Insulation Class | Supply Voltage Tolerance | Working Llfe |
12000 | 100 | DC:B AC:H | +10～-15 |  |
 |  |
