Main technical data:
Rated Magnetic (N) | Rated Stroke (mm) | Full stroka (mm) | Power Consumption (W) | Oil Pressure Duration (Mpa) |
54 | 4 | ≥8.5 | ≤38 | 21 |
Max Operation Frequency (t/h) | Duty Cycle (%) | Insulation Class | Supply Voltage Tolerance | Working Llfe |
12000 | 100 | H | +10～-15 |  |
 |  |
